Nureva HDL300

HDL300

Technology features

Powerful onboard system processors
Continuous autocalibration
Position-based gain control
Acoustic echo cancellation
Built-in sound masking
Primary audio source for video playback
Single Ethernet cable to microphone and speaker bar
Integrated, multicolor status LED

Microphones

12 – low-noise omnidirectional MEMS

Frequency response at 94 dB SPL 100Hz to 7 kHz

Total harmonic distortion (THD) 0.25% (typical)

Speakers

2 – 20W 4″ aluminum cone

Acoustic output (hardware capable) 91 dB-SPL @ 1m

Total harmonic distortion (THD) 0.25% typical

CONNECT MODULE

1 – USB 2.0 interface to computer, type B

1 – Auxiliary out – 3.5 mm single-ended stereo jack

1 – Auxiliary in – 3.5 mm single-ended stereo jack

2 – Connections to microphone and speaker bar RJ-45

1 – Input jack for power supply

INTEROPERABILITY

Certified for Microsoft Teams. Plug and play compatibility with UC&C platforms including Zoom, Google MeetTM, GoToMeeting®, Cisco Webex®, Blue Jeans, Lifesize®, RingCentral, Fuze Rooms and more

Easy integration with third-party solutions such as Barco ClickShare, lecture capture systems and headset microphones (for Voice Amplification Mode)

Operating system

Windows® 10 and 11
Mac® OS X® 10 and 11
(Big Sur and Catalina)

Power

Power rating: universal switching 100-240V AC, 50-60Hz

Power consumption: standby <2.5W, operational <25W

Environmental

Operating temperature: 0° C to 40° C
(32° F to 104° F)

Storage temperature: -20° C to 70° C (-4° F to 158° F), humidity 5–90% (noncondensing)

MANAGEABILITY

Automatic firmware updates

Remote management features available through cloud-based Nureva Console

CERTIFICATIONS AND COMPATIBILITY

Electromagnetic

FCC Part 15, Class A; ICES-003, Class A; CISPR 32 (EN55032), Class A; CISPR 35 (EN55035); CISPR24 (EN55024)

Safety

UL 62368; CAN/CSA-C22.2 NO.62368; IEC/EN62368; AS/NZS 62368; UL 60950; CAN/CSA-C22.2 NO.60950; IEC/EN60950; AS/NZS 60950

Compliance

RoHS, REACH, PoP (Persistent Organic Pollutants), WEEE compliance, California Proposition 65, EPA (TSCA-Toxic Substances Control Act) Restrictions

DIMENSIONS

HDL300

Width: 60.0″ (152.4 cm)
Height: 5.91″ (14.9 cm)
Depth: 3.5″ (9.0 cm)
Weight: 18.0 lb. (8.2 kg)

Connect module

Width: 6.5″ (16.5 cm)
Height: 1.41″ (3.6 cm)
Depth: 4.31″ (10.9 cm)
Weight: 1.5 lb. (0.7 kg)

Shipping

Width: 64.75″ (164.4 cm)
Height: 10.63″ (27.0 cm)
Depth: 9.5″ (24.1 cm)
Weight: 24.0 lb. (10.9 kg)

INCLUDES

Integrated microphone and speaker bar
Connect module, white
Connect module mounting bracket, white
Country specific power cable, 6′ (2.5 m), black
Ethernet cable, CAT6 SSTP, 50′ (15 m), Class 3 rated, black
USB Type A-B cable, 10′ (3 m), VW-1 rated, black
Infrared remote with 2 AAA batteries
Documentation

WARRANTY

Integrated microphone and speaker bar and connect module – standard 2-year limited hardware

Accessories and cables – 30 days

Extended warranties are available through Nureva Pro subscriptions

PART NUMBERS

Black: HDL300-B
White: HDL300-W

Nureva Pro extension (1 year): NP-1Y
Nureva Pro extension (2 years): NP-2Y
Nureva Pro extension (3 years): NP-3Y
