Ecler IC6

Ecler IC6

6.5″ | 2-way | 40 WRMS | rust-proof grill

Category: Tag:

Description

DESCRIPTION

IC6 2-way loudspeaker is the perfect option for 70/100 V and low impedance sound solutions. It mounts a 6.5” woofer and a 1″ tweeter in a discreet design. IC series provides excellent sound quality thanks to their infinite baffle philosophy and a top-performance high frequency transducer.



FEATURES

  • 2 way speaker for false ceilings
  • 6” polypropylene woofer
  • 25mm tweeter
  • Power: 40W RMS @ 8 ohm
  • Sensitivity (1W/1m): 93 dB SPL
  • Built-in transformer
  • External diameter: 204mm
  • Cut out diameter: 180mm
  • Available in black (RAL9005) or white (RAL9010) finish
  • Installation system: Three revolving fasteners



SPECS

SYSTEM

  • Effective Freq. Range : 75 Hz- 20 kHz (-10dB)
  • Coverage angle / Dispersion : 145°x145° (HxV)
  • Power handling : 40 W RMS / 160 W Peak
  • Sensitivity : 93 dB (1W/1m)
  • Maximum SPL : 109 dB continuous / 115 dB peak
  • Power options (Hi Z Multi-tap) :
    • 100V: 15W / 7,5W / 5W / 2,5W / 8Ω
    • 70V: 7,5W / 3,75W / 2,5W / 1,25W / 8Ω
  • Recommended amplifier power : 80 W RMS

TRANSDUCERS

  • Ways : 2-ways full range
  • Low frequency driver : 6,5″ woofer
  • High frequency driver : 1″ tweeter
  • Nominal impedance :  8Ω

PHYSICAL



  • Connection type : Clip-type input terminals
  • Power type selector : Rotary power tap selector
  • Installation options : In-ceiling, in-wall
  • Enclosure material : ABS
  • Grille material : Aluminium rust proof
  • Mounting system : 3 rotating tabs
  • Operating temperature
    • Min: -10°C ; 14°F
    • Max: 40°C ; 104°F
  • Operating humidity : <85% HR
  • Storage temperature :
    • Min: -10°C ; 14°F
    • Max: 40°C ; 104°F
  • Storage humidity : <90% HR
  • External diameter : 204 mm / 8.03″
  • Internal diameter : 178 mm / 7.00″
  • Recommended cut out diameter : 180 mm / 7.40″
  • Required depth : > 73 mm / 2.87″
  • Ceiling thickness :
    • 5mm / 0.19″ min
    • 20mm / 0.78″ max
  • Included accessories :  Cutting and painting templates included
  • Finished colour : White (RAL 9010) or Black (RAL 9005)
  • Weight : 1.5 kg / 3.30 lb
  • Pieces per box :  2 units
  • Shipping dimensions : 240 x 250 x 220 mm / 9.4 x 9.8 x 8.66 in. (WxHxD)
  • Shipping weight : 1.90 kg / 4.18 lb
