Xilica Gio XLR

Neutrik XLR 2×2 to Dante in-wall module, suitable for single-gang EU/UK installation or dual-gang US electrical boxes. Single CatX for power and data.

Category: Tag:

Description

  • Power-over-Ethernet

    IEEE 802.3af, Class 0

  • Power Consumption

    5W maximum

  • Operating Temperature

    32-104⁰F (0-40⁰C)

  • Ethernet

    (1) RJ45 with Link and Speed indicators

  • Audio Networking

    Dante™ with AES67-compliance
    44.1 kHz, 48kHz supported sample rates

  • Audio Inputs

    (2) Three-pin Neutrik XLR (balanced)
    Mic/Line level (software-selectable)
    48V Phantom Power (software-selectable)
    Up to +45dB in 5dB steps, adjustable per input

  • Audio Outputs

    (2) Three-pin Neutrik XLR (balanced)
    Mic/Line level (software-selectable)
    0dB to -60dB, 1dB increments (adjustable per output)

  • Controls, Service & Indicators

    LED indicator for Power and Status
    Momentary button for network discovery and reset

  • Finish

    Black, gloss

  • Weight

    0.4 lbs / 0.2 kg

  • Dimensions (HxWxD)

    4.2″ x 3.5″ x 2.0″ (106.7 x 88.9 x 50.8mm)

  • Mounting

    Mounts into single-gang EU/UK electrical box, or US dual-gang electrical box with included mud-ring.

  • Compliance

    FCC Part 15B, CE, RoHS Directive, WEEE

  • Warranty

    Xilica Three Year Limited Warranty

  • Part Number(s)

    2200-003-0402
